To improve hydrogen storage, a research team led by Wendelin Stark, Professor of Functional Materials at the Department of Chemistry and Applied Biosciences, is relying on the steam-iron process, which has been understood since the 19th century. If there is a surplus of solar power available in the summer months, it can be used to split water to produce hydrogen. This hydrogen is then fed into a stainless steel reactor filled with natural iron ore at 400°C. There, the hydrogen extracts the oxygen from the iron ore – which, in chemical terms, is simply iron oxide – resulting in elemental iron and water. Similar to charging a battery, this chemical process allows the energy in the hydrogen to be stored as iron and water for long periods with almost no losses. When the energy is needed again in winter, the researchers reverse the process: they feed hot steam into the reactor to turn the iron and water back into iron oxide and hydrogen. The hydrogen can then be converted into electricity or heat in a gas turbine or fuel cell. To keep the energy required for the discharging process to a minimum, the steam is generated using waste heat from the discharging reaction.
Cheap iron ore meets expensive hydrogen
“The big advantage of this technology is that the raw material, iron ore, is easy to procure in large quantities. Plus, it doesn’t even need processing before we put it in the reactor,” says Stark. Moreover, the researchers assume that large iron ore storage facilities could be built worldwide without substantially influencing the global market price of iron.
The reactor in which the reaction takes place does not need to fulfil any special safety requirements either. It consists of stainless steel walls just 6 millimetres thick. The reaction takes place at normal pressure, and the storage capacity increases with each cycle. Once filled with iron oxide, the reactor can be reused for any number of storage cycles without having to replace its contents. Another advantage of the technology is that the researchers can easily expand the storage capacity – simply by building larger reactors and filling them with more iron ore. All these advantages make this storage technology an estimated ten times cheaper than existing methods.
However, there is also a downside to using hydrogen: its production and conversion are inefficient compared to other sources of energy, with up to 60% of its energy lost in the process. This means that as a storage medium, hydrogen is most attractive when sufficient wind or solar power is available and other options are off the table. This is especially true for industrial processes that cannot be electrified.
Pilot plant on the Hönggerberg campus
The researchers have demonstrated the technical feasibility of their storage technology using a pilot plant on the Hönggerberg campus. This plant consists of three stainless steel reactors, each with a capacity of 1.4 cubic meters, filled with 2–3 tonnes of untreated iron ore available on the market.
“The pilot plant can store around 10 megawatt hours of hydrogen over long periods. Depending on how you convert the hydrogen into electricity, that’ll give you somewhere between 4 and 6 megawatt hours of power,” explains Samuel Heiniger, a doctoral student in Stark’s research group. This corresponds to the electricity demand from three to five Swiss single-family homes in the winter months. At present, the system is still running on electricity from the grid and not on the solar power generated on the Hönggerberg campus.
This is soon set to change: the researchers want to expand the system so that by 2026, the ETH Hönggerberg campus can meet one-fifth of its winter electricity requirements using its own solar power from the summer. This would require reactors with a volume of 2,000 cubic metres, which could store around 4 gigawatt hours (GWh) of green hydrogen. Once converted into electricity, the stored hydrogen would supply around 2 GWh of power. “This plant could replace a small reservoir in the Alps as a seasonal energy storage facility. To put that in perspective, it equates to around one-tenth of the capacity of the Nate de Drance pumped storage power plant,” Stark says. In addition, the discharging process would generate 2 GWh of heat, which the researchers want to integrate into the campus’s heating system.
Scalability
But could this technology be harnessed to provide seasonal energy storage for Switzerland as a whole? The researchers have made some initial calculations: providing Switzerland with around 10 terawatt hours (TWh) of electricity from seasonal hydrogen storage systems every year in the future – which would admittedly be a lot – would require some 15–20 TWh of green hydrogen and roughly 10,000,000 cubic metres of iron ore. “That’s about 2% of what Australia, the largest producer of iron ore, mines every year,” Stark says. By way of comparison, in its Energy Perspectives 2050+, the Swiss Federal Office of Energy anticipates total electricity consumption of around 84 TWh in 2050.
If reactors were built that could store around 1 GWh of electricity each, they would have a volume of roughly 1,000 cubic metres. This calls for around 100 square metres of building land. Switzerland would have to build some 10,000 of these storage systems to obtain 10 TWh of electricity in winter, which corresponds to an area of around 1 square metre per inhabitant.
